    SKD61 PET Bottle Mould Manufacturer 9kw PET Moulding 730x450x480mm

    Ask Lasest Price
    Brand Name : Eceng
    Supply Ability : 50000 Set/Sets per Year
    Certification : CE SGS ISO
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 30days
    • Product Details
    • Company Profile

    SKD61 PET Bottle Mould Manufacturer 9kw PET Moulding 730x450x480mm

    Eceng Multi Cavities PET 28MM 28g bottle Preform Mould manufacturer in china with Hot Runner


    The Specification Of Hot Runner Preform Mould
    Cavities24-cavities
    Mould frame material4Cr13 Stainless steel
    Core materialS136
    cavity materialS136
    Valve Pin BrandSKD61 (Japan)
    Heat insulation tip BrandDuPont(America)
    Heater ring brandHotest(Germany)
    Runner structure
    enter runnerone gate
    base runner3 points
    Sub channel24 points
    Mould information
    Mold outline size730x450x480mm
    Mould weight1300KGS
    The mould featuresSelf-lock,air seal, valve gate
    Cycle times28 seconds
    Mould power9 kw
    After-sales Service
    Mould lifeMore than 3 million shot injection times
    Guarantee periodOne Year
    Payment terms

    50% deposit in advance

    50% balance before shipping

    Packaging requirement
    standard export packaging.
    Product informationNeck size:30mm
    Weight:13grams

    Eceng Multi Cavities PET 28MM 28g bottle Preform Mould manufacturer in china with Hot Runner

    instructions
    1: The number of preform cavity from 1 to 96.
    2: The bottle preform is designed by computer simulation tensile test to improve the finished product rate of the blown bottle.
    3: Adopt the world advanced two-level double-taper positioning technology, each cavity is self-locked independently, to ensure the concentricity of the mold.
    4: Mold injection cavity and injection core are made of high quality preheating special die steel from the original Factory in Sweden.
    5: Thread mouth according to international standard manufacturing, the material selection of imported nitriding, high hardness, long service life. 6: Advanced design of hot runner, uniform heating temperature, improve the quality of plastic products.
    7: no shear gate, reduce the labor intensity of workers.
    8: Mold life is guaranteed to be more than 3 million mold times.

    Our company specializes in manufacturing plastic machinery and moulds. We are mainly engaged in making automatic PET blow mould machine, semi-automatic PET blow machine, PE/PP/PVE/HDPE extruding blowing machine, injection machine and all kinds of moulds. We have been committed to the design of plastic bottle making machine, especially the fully-automatic PET blow mould machine, from 300ml- 20L. Our machine complying with CE certification has good quality with praise by our customers. Our standard spares are free. We insist on quality first. What's more, we design kinds of plastic moulds for domestic and foreign customers. With a professional design team, we use advanced CAD / CAM / CAE system. We have gained a well-known reputation from our customers.

    FAQ

    1. who are we?
    We are based in Jiangsu, China, start from 20O7,sell to Southeast Asia(30.00%),Africa(20.00%),Domestic Market(20.00%),Mid East(15.00%),South America(10.00%),North America(5.00%). There are total about 11-50 people in our office.
    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;
    3.what can you buy from us?
    Fully Auto Bottle Blowing Machine
    4. why should you buy from us not from other suppliers?
    We have been committed to the design of plastic bottle making machine, especially the fully-automatic PET blow mould machine, from 300ml- 20L. Our machine complying with CE certification has good quality with praise by our customers.
    5. what services can we provide?
    Accepted Delivery Terms: FOB,CIF,EXW;
    Accepted Payment Currency:USD,EUR,CNY;
    Accepted Payment Type: T/T,L/C,Western Union;
    Language Spoken:English,Chinese
